SR 500
Art.nr. H06-0112
SR 570 Face shield
Art.nr. H06-6512
Face shield
The SR 570 face shield is a modern, innovative product, designed and developed based on the needs and requirements from the market.
The SR 570 is a robust shield with a flip-up visor, and gives the user comfortable and safe respiratory and eye protection. The face shield
is fitted with an attachment for hearing protectors.
A wide range of accessories enable the user to customise the shield for their work situation. The shield is manufactured in a material
that permits use in tough environments.
The SR 570 shield can be used with either our SR 500 SR 500 EX or SR 700 powered fan unit. It can also be used with the compressed air attachment SR 507.
- Number
- H06-6512
- Material
- PC/ABS, PA, PC
- Color
- Blue, Black
- Shelf life (years)
- 5
- Country of manufacture
- Sweden
- Operating temp.
- -10 – +55 °C, < 90 % RH
- Storage temp.
- -20 – +40 °C, < 90 % RH
- Model
- SR 570
- Assign. protection factor
- 40 (3A,3B), 40 (TH3)
- Nom. protection factor
- 200 (3A,3B), 500 (TH3)
- Approval
- EN 12941:1998 + A2:2008, EN 14594:2005, EN 166
- Directive 1
- (EU) 2016/425 PPE
- Directive 2
- ATEX 2014/34/EU
- Classification 2
- II G Ex ib IIB T3 Gb, II 2 D Ex ib IIIC T195° Db
Instruction for use
L67-6510-SR-570-Rev-08.pdfExploded view
SPRH06-6518-SR-570-Rev-05.pdfProduct leaflet
P06H-6518-SR-570-Rev-05.pdfOperating instructions
OI06H-6518-SR-570-Rev-03.pdf- Related products and systems
- Accessories
- Spare parts
