SR 500 EX
Art.nr. H06-2012
Easily operated battery powered fan with particle- or combination filters.
The SR 500 EX fan is explosion-proof and specially adapted for use in an explosive atmosphere. The SR 500 EX is included together with filters and head-tops in Sundström fan-assisted respiratory protective devices. The SR 500 EX can be used as an alternative to filter protections in all situations in which the latter are recommended. This applies particularly to situations in which the work is intensive, hot or of long-duration. The fan is equipped with filters and the filtered air is supplied through a breathing hose to the head-top. The latter is then pressurized, which prevents the surrounding pollutants from being admitted.
- Approval
- EN 12941:1998 + A2:2008, EN 12942:1998 + A2:2008, EN 60079-0:2018, EN 60079-11:2012, IEC 60079-11:2011, IEC 60079-0:2017
- Cell type
- Li-Ion 18V, 3.0 Ah
- Classification 2
- II G Ex ib IIA T3 Gb, II G Ex ib IIB T3 Gb, II 2 D Ex ib IIIC T195° Db
- Color
- Black, Orange
- Country of manufacture
- Sweden
- Directive 1
- (EU) 2016/425 PPE
- Directive 2
- ATEX 2014/34/EU
- Model
- SR 500 EX
- Number
- H06-2012
Product leaflet
P06H-2018-SR-500-EX-Rev-17.pdfExploded view
SPRH06-2018-SR-500-EX-Rev-07.pdfOperating instructions
OI06H-2018-SR-500-EX-Rev-05.pdfDeclaration of conformity
EU-Declaration-of-Conformity-PPE20161986_SR-540-EX.pdfExploded view
SPRH06-2118-SR-500-EX-System-overview-Rev-09.pdfInstruction for use
L67-2010-SR-500-EX-Rev-17.pdfDeclaration of conformity
EU-Declaration-of-Conformity-ATEX-Directive_SR-500-EX.pdfProduct leaflet
SR_TRUST_folder.pdfDeclaration of conformity
EU-Declaration-of-Conformity-EMC-Directive_SR-500-EX.pdfDeclaration of conformity
UKCA-Declaration-of-Conformity-SR-500-EX.pdf- Related products and systems
