SR 580
Art.nr. H06-8012
SR 700 Fan unit UK
Art.nr. H06-7018
Easily operated battery powered fan with particle filters.
The SR 700 is a battery-powered fan that, together with particle filter SR 510 P3 R or SR 710 P3 R and an
approved head top, is included in the Sundström fan-assisted respiratory protective device systems. The SR
700 can be used as an alternative to filter respirators in all situations in which these are recommended. This
applies particularly to work that is hard, warm or of long duration.
The fan is equipped with filter, and the filtered air is fed through a hose to the human interface. The pressure
then generated prevents surrounding pollutants from penetrating into the mask.
- Number
- H06-7018
- Material
- ABS, Activated carbon, Aluminium, CA, Cotton, EPDM, Fabric, Glass, , Impregnated activated carbon, Leather, NX, PA, PC, PC/ABS, PE, PEHD, PET, PETG, Polyester, , PP, Proban, PUR, PVC, Rubber, Silicone, Steel, TAC, TPE, Tyvek®
- Color
- Black, Blue, Brown, Gold, Green, Grey, Magenta, Olive, Orange, Silver, Transparent, White, Yellow
- Shelf life (years)
- 5
- Country of manufacture
- Sweden
- Operating temp.
- -10 – +55 °C, < 90 % RH
- Storage temp.
- -20 – +40 °C, < 90 % RH
- Model
- SR 700
- Assign. protection factor
- 40 (TH3), 40 (TM3)
- Nom. protection factor
- 500 (TH3), 2000 (TM3)
- Cell type
- Li-Ion 14,4V 2,25 Ah
- Approval
- EN 12941:1998 + A2:2008, EN 12942:1998 + A2:2008
- Directive 1
- (EU) 2016/425 PPE
Instruction for use
L67-0710-SR-700-Rev-17.pdfOperating instructions
OI06H-7018-SR-700-Rev-05.pdfProduct leaflet
P06H-0718-SR-700-Rev-14.pdfExploded view
SPRH06-7118-SR-700-System-overview-Rev-06.pdf- Related products and systems
- Accessories
- Spare parts
