SR 500
Art.nr. H06-0112
SR 570 Face shield (TAC visor) and bump cap.
Art.nr. H10-0047
Face shield with chemical resistant (TAC) triacetate visor.
The SR 570 face shield is a modern, innovative product, designed and developed based on the needs and requirements from the market.
The SR 570 is a robust shield with a flip-up visor, and gives the user comfortable and safe respiratory and eye protection. The face shield
is fitted with an attachment for hearing protectors.
A wide range of accessories enable the user to customise the shield for their work situation. The shield is manufactured in a material
that permits use in tough environments.
The SR 570 shield can be used with either our SR 500 / SR 500 EX or SR 700 powered fan unit. It can also be used with the compressed air attachment SR 507.
- Number
- H10-0047
- Material
- ABS, Activated carbon, Aluminium, CA, Cotton, EPDM, Fabric, Glass, , Impregnated activated carbon, Leather, NX, PA, PC, PC/ABS, PE, PEHD, PET, PETG, Polyester, , PP, Proban, PUR, PVC, Rubber, Silicone, Steel, TAC, TPE, Tyvek®
- Color
- Black, Blue, Brown, Gold, Green, Grey, Magenta, Olive, Orange, Silver, Transparent, White, Yellow
- Shelf life (years)
- 5
- Country of manufacture
- Sweden
- Operating temp.
- -10 – +55 °C, < 90 % RH
- Storage temp.
- -20 – +40 °C, < 90 % RH
- Model
- SR 570
- Assign. protection factor
- 100 (3A,3B), 200 (TH3)
- Nom. protection factor
- 200 (3A,3B), 500 (TH3)
- Approval
- EN 12941:1998 + A2:2008, EN 14594:2005, EN 166, EN 812:2012
- Directive 1
- (EU) 2016/425 PPE
- Directive 2
- ATEX 2014/34/EU
- Classification 2
- II G Ex ib IIB T3 Gb, II 2 D Ex ib IIIC T195° Db
- Translated
- Swedish (sv), Norwegian , Finnish , Spanish , French , German , Polish , Thai , Chinese
Instruction for use
L67-6510-SR-570-Rev-08.pdfExploded view
SPRH06-6518-SR-570-Rev-05.pdfProduct leaflet
P06H-6518-SR-570-Rev-05.pdfOperating instructions
OI06H-6518-SR-570-Rev-03.pdf- Related products and systems
- Accessories
- Spare parts
