SR 518 A2
Art.nr. H02-7012
SR 597 A1BE2K1
Art.nr. H02-7212
Filter for protection against gases and fumes with optimized adsorption.
The SR 597 A1BE2K1 gas filter are intended for use in the SR 500/SR 500 EX fan.
The filter type protect against the following gases/vapours:
Type A protects against organic gases and vapours, such as solvents, with boiling points > +65 °C.
Type B protects against inorganic gases and vapours, such as chlorine, hydrogen sulphide and hydrogen cyanide.
Type E protects against acidic gases and vapours, such as sulphur dioxide and hydrogen fluoride.
Type K protects against ammonia and certain amines, such as ethylene diamine.
The SR 500/SR 500 EX fan unit must always be used with two particle filters or two combined filters consisting of
gas filters and particle filters.
- Number
- H02-7212
- Material
- ABS, Activated carbon, Aluminium, CA, Cotton, EPDM, Fabric, Glass, , Impregnated activated carbon, Leather, NX, PA, PC, PC/ABS, PE, PEHD, PET, PETG, Polyester, , PP, Proban, PUR, PVC, Rubber, Silicone, Steel, TAC, TPE, Tyvek®
- Color
- Black, Blue, Brown, Gold, Green, Grey, Magenta, Olive, Orange, Silver, Transparent, White, Yellow
- Shelf life (years)
- 5
- Country of manufacture
- Sweden
- Operating temp.
- -10 – +55 °C, < 90 % RH
- Storage temp.
- -20 – +40 °C, < 90 % RH
- Model
- SR 597
- Filter Type
- ABEK
- Approval
- EN 12941:1998 + A2:2008, EN 12942:1998 + A2:2008
Product leaflet
P02H-7018-SR-515_SR-518_SR-597-Rev-09.pdfInstruction for use
L27-1310-Filter-Rev-06.pdf- Related products and systems
- Accessories
