SR 500 EX Fan unit UK
Art.nr. H06-2018
Easily operated battery powered fan with particle- or combination filters.
The SR 500 EX fan is explosion-proof and specially adapted for use in an explosive atmosphere. The SR 500 EX is included together with filters and head-tops in Sundström fan-assisted respiratory protective devices. The SR 500 EX can be used as an alternative to filter protections in all situations in which the latter are recommended. This applies particularly to situations in which the work is intensive, hot or of long-duration. The fan is equipped with filters and the filtered air is supplied through a breathing hose to the head-top. The latter is then pressurized, which prevents the surrounding pollutants from being admitted.
- Number
- H06-2018
- Material
- ABS, Activated carbon, Aluminium, CA, Cotton, EPDM, Fabric, Glass, , Impregnated activated carbon, Leather, NX, PA, PC, PC/ABS, PE, PEHD, PET, PETG, Polyester, , PP, Proban, PUR, PVC, Rubber, Silicone, Steel, TAC, TPE, Tyvek®
- Color
- Black, Blue, Brown, Gold, Green, Grey, Magenta, Olive, Orange, Silver, Transparent, White, Yellow
- Shelf life (years)
- 5
- Country of manufacture
- Sweden
- Operating temp.
- -10 – +40 °C, < 90 % RH
- Storage temp.
- -20 – +40 °C, < 90 % RH
- Model
- SR 500 EX
- Cell type
- NiMh 13,5V 2,1 Ah
- Approval
- EN 12941:1998 + A2:2008, EN 12942:1998 + A2:2008, EN 60079-0:2012, EN 60079-11:2012, EN 13463-1:2009
- Directive 1
- (EU) 2016/425 PPE
- Classification 1
- II G Ex ib IIA T3 Gb, II G Ex ib IIB T3 Gb, II 2 D Ex ib IIIC T195° Db
- Directive 2
- ATEX 2014/34/EU
